FANUC Controlled Heavy-duty Machining Center GV2030 | Dedicated to High-Precision Automotive Parts Manufacturing

Request a quote today and experience precision engineering tailored for your automotive manufacturing needs.
Ningbo Kaibo CNC Machinery Co., Ltd. Ningbo, Zhejiang, China
https://shmuker.oss-accelerate.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807140221/heavy-duty-machining-center-with-fanuc-controller-gv2030-1.jpg
https://shmuker.oss-accelerate.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807140221/heavy-duty-machining-center-with-fanuc-controller-gv2030-2.jpg
https://shmuker.oss-accelerate.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807140221/heavy-duty-machining-center-with-fanuc-controller-gv2030-3.jpg
https://shmuker.oss-accelerate.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807140221/heavy-duty-machining-center-with-fanuc-controller-gv2030-4.jpg
https://shmuker.oss-accelerate.aliyuncs.com/data/oss/60f057d7801008393c7f3dd7/66a70b5c6ab1dc323153e13a/20240807140221/heavy-duty-machining-center-with-fanuc-controller-gv2030-6.jpg

Recommended Products

Product Parameters
accuracy
positioning accuracy: 0.01 mm
Repeatability: 0.005 mm
See more
Workbench
Work table size: 2000*3000mm
T-slot dimensions: 8T-18-180 mm
Weight capacity: 8000 kg
Processing range
X/Y/Z axis travel: 2000/3000/1000 mm
Gantry width: 2020 mm
Beam to workbench: 1200 mm
Distance from spindle nose to worktable: 150-1150 mm
Door opening width: 2060 mm
feed
Maximum feed speed G00: 20 m/min
Maximum working speed G01: 8m/min
X/Y/Z axis motor power: αiF30/αiF40/αiF30
Spindle
Spindle motor power: αilP40-18.5KW
Maximum spindle speed: 6000 rpm
Tool holder: BT50
Spindle diameter: -
Common
Power supply and total capacity: 3P/380V/50Hz/30KVA
Machine weight: 32000 kg
aspect: 8300*4900*4850mm
Main Components
Controller: Fanuc/Japan0i-MF
AC servo motor (driver): FANUC/Japan
Spindle inverter: FANUC/Japan
Linear Guides: 55(6,8,12)Hiwin,PMI/Taiwan
Ball Screw: 6310/6310/5010Hiwin, PMI/Taiwan
Electronic handwheel: EHDW-BA5S-1 Future/Taiwan
Lubrication system: YET-A2P2ISHAN/Taiwan
Oil coolant cooler: Parsenhal/China
air conditioner: EA-6A Parsons/China
Pneumatic system: AirTac/Taiwan
Chip conveyor: Internal thread type
Water tank capacity: -
Water pump power: 1000W
Tool library (optional)
ATC Type: Arm Type
Air traffic control capabilities: 24 items
Close
Product Details
Product Introduction
The KEBON CNC GV2030 Heavy-Duty Machining Center is engineered specifically for high-precision production of automotive components such as engine blocks, transmission housings, and molds. Equipped with a reliable FANUC control system, this dual-column, large-travel CNC milling machine delivers exceptional rigidity, accuracy, and productivity—ideal for both complex geometries and high-volume batches. Certified to ISO9001 standards, the GV2030 supports customized configurations including spindle options, tool changers, and color finishes. Backed by a 1-year warranty and 24/7 technical support, plus service networks across 26 global locations, KEBON ensures long-term operational stability and seamless integration into your smart manufacturing workflow.
Advantages and features
1. Dual-column design ensures superior rigidity and vibration resistance for consistent precision in demanding automotive applications.2. FANUC controller offers industry-leading reliability, ease of programming, and compatibility with advanced automation systems.3. Customizable configurations (spindle speed, tool magazine, worktable size) allow optimization for specific part types and production volumes.4. ISO9001-certified quality assurance guarantees consistent performance and compliance with international manufacturing standards.5. Global service network with 26+ support centers enables fast response times and minimal downtime for overseas clients.
Application Scenario
Ideal for automotive OEMs, Tier 1 suppliers, and mold manufacturers worldwide seeking efficient, accurate, and scalable solutions for engine, transmission, and chassis component machining. Suitable for markets in North America, Europe, Asia-Pacific, and emerging economies where high-quality CNC machining is essential for competitive manufacturing.
Corporate Information
Ningbo Kaibo CNC Machinery Co., Ltd.
100%
On-time delivery rate
Less than 3 hours
Response time
52000
Construction area
Service Guarantee
Service Information
Address
Industry Area of ​​Changjie, Ninghai, Ningbo, Zhejiang, China
Advisory Message
Pre-sales advice
Equipment can be customized according to your requirements (machine configuration, color...)
After-sales service
1. After-sales guarantee: We provide one-year free quality assurance service for the products we sell to ensure the stability and reliability of the products.
2. Technical support: The company has 26 sales service offices, equipped with professional technicians, who can answer customer questions online 24/7 and provide remote or on-site technical support.
3. Training service: Provide customers with free operation and maintenance training to ensure that customers can use and maintain the equipment proficiently.
4. Accessories supply: Provide original accessories for a long time to ensure the continuous and normal operation of customers' equipment.
5. Customer Feedback: Respond to customer feedback in a timely manner and continuously improve products and services to meet customer needs to the greatest extent possible.
Specific details
Please contact us
Product Specifications Reference
Spindle type
BT50/15kw/6000-8000rpm mechanical spindle More spindles
Tool magazine type
Arm type tool magazine (24 pieces) Arm type tool magazine (32 pieces) Chain tool magazine (40 pieces) Umbrella tool magazine (20 pieces)

Payment method

L/C
L/C
T/T
T/T
D/P
D/P
D/A
D/A

Means of transaction

Communication
Direct Exporting
Indirect Exporting

Refunds

Contact us for details
